MDI Mercury Contactor, 36 DC volt Coil, 30 Amps, 3 Pole, 330NO36D
Special Price
$88.00
was
$96.00
SKU
MDI-Mercury-Contactor-330NO36D
MDI 3-Pole Mercury Contactor 330NO36D Normally Open
36 DC Volt Coil and 30 Amps
36 DC Volt Coil and 30 Amps
MDI Mercury Contactor 330N036D, three pole, 30 amps, 0 - 600 volts output, 36 volts DC Coil Voltage. MDI Mercury Relays can switch up to 600 volts AC based on amperage load. MDI relays can switch millions of cycles, out performing mechanical relays. MDI relays can operate in very high temperatures as well as cold temperatures, with no heat sink required. Mercury Contactors must be mounted in a vertical position in order to function. 1 Year Warranty. CE, UL approved and CSA listed.
| Brand | MDI |
|---|---|
| MFR Part Number | 330NO36D |
| Old MFR Part Number | 330NO36D-18 |
| MPN Alternate | 330N036D |
| Application | Industrial Heating |
| Number of Poles | 3 |
| Color | Black |
| Condition | New |
| Explosion Proof | Yes |
| Install Options | Indoor |
| Model | MDI Mercury Contactor 330N036D |
| Phase | 1 |
| Product Dimensions (Inches) | 4 x 3 x 4 |
| Amperage (Amps) | 30 |
| Voltage (Volts) | 36 VDC |
| Water Resistant/Hosedown | Yes |
